Overview
Automatic Extrusion Blow Molding Machine for Sale — Specifications & HDPE Container Production
US packaging and industrial buyers comparing an automatic extrusion blow molding machine for sale against used blow molding machines need matched clamping force, carriage stroke, and HDPE containers volume before quoting molds, chillers, and downstream advanced automation.
| Configuration | Clamping Force | Carriage / Opening Stroke | Container Range | Typical FOB Range |
|---|---|---|---|---|
| BP-EBM25 | 35–55 ton | 800 mm / 320 mm | 0.1L–10L | $19,000–$35,000 |
| BP-EBM45 | 65–90 ton | 1,100 mm / 360 mm | 1L–60L | $38,000–$58,000 |
| BP-EBM90 | 100–120 ton | 1,300 mm / 380 mm | 10L–220L | $55,000–$85,000 |
Unlike semi-automatic blow molding PET stretch lines, this extrusion blow moulding machinery extrudes a parison and blows HDPE containers, jerrycans, and automotive hollow parts in one continuous cycle — see our extrusion blow molding machine hub for line-matched tooling packages.
High-Speed Automation
Our extrusion blow moulding machinery features a high-speed double station blow molding machine setup and automated deflashing. By automating parison cutting, clamping, and trimming, we minimize cycle times and eliminate manual labor overhead.
Precision Wall Thickness Control
Achieving uniform material distribution requires advanced technology. Our integrated parison control system dynamically adjusts the parison profile during extrusion. This prevents thin spots, reduces plastic waste, and ensures optimal top-load strength for every container.
Energy-Saving Drive Technology
Rising utility costs impact your bottom line. BlowPacker utilizes an energy-saving blow molder platform equipped with servo-hydraulic systems and high-efficiency motor drives. This setup cuts power consumption by up to 40% compared to traditional plastic processing equipment.
Modular Design
Your production needs will evolve, and our plastic processing machinery is built to adapt. The modular frame allows for quick die head configuration changes, effortless upgrades to multi-layer co-extrusion, and flexible scaling for different clamping unit force requirements.
BlowPacker Core Advantages At a Glance
| Feature | Production Benefit | Target Application |
|---|---|---|
| Advanced Automation | Multi-cavity high-speed production with zero manual trimming | Automatic plastic bottle making machine lines |
| Servo-Driven Systems | Lower footprint, low noise, and reduced oil maintenance | Energy-saving blow molder operations |
| Parison Optimization | 100-point thickness control for exact material distribution | HDPE container blow molder manufacturing |
| Flexible Die Heads | Seamless switching between single and multi-cavity runs | Continuous extrusion blow molding system setups |
Core Specifications of Our Automatic Extrusion Blow Molding Machine for Sale
We build our equipment to handle tough production schedules without breaking a sweat. If you are looking for a reliable automatic extrusion blow molding machine for sale, you need to know exactly what is under the hood. Here is the technical breakdown of how our plastic processing machinery delivers high performance day in and day out.
Clamping Unit
Our robust clamping unit force ensures perfectly sealed seams on every single part.
High-Stiffness Platen Design: Prevents deflection and ensures even pressure distribution.
Optimized Carriage Stroke & Opening Stroke: Fast movements that cut down cycle times significantly.
Tie-Bar-Less or Heavy-Duty Tie-Bar Options: Gives you flexible mold installation and easy access.
Extrusion System
We design our continuous extrusion blow molding system for uniform melting and consistent parison weight.
High-Output Screw & Barrel: Optimized specifically for HDPE containers and PP processing.
Energy-Saving Drive Motor: Precision frequency-inverter motor control reduces power consumption while maintaining high torque.
Die Head
The die head configuration determines your product quality. We use advanced flow channel designs to eliminate knit lines.
Precision Parison Control System: Up to 100-point thickness programming to save material and maximize strength.
Quick-Change Design: Drastically reduces downtime during color or material switchovers.
Control System
Get complete command over your production line with our user-friendly, intelligent setup.
Touchscreen Interface: Intuitively manage temperatures, movements, and parison profiles.
Real-Time Monitoring: Closed-loop control systems track every parameter to keep production flawless.
Utility Requirements
Here is what you need to integrate this fully automatic EBM machine into your factory floor:
| Utility Component | Operational Requirement |
|---|---|
| Electrical Power | 460V / 3 Phase / 60Hz (Standard US Voltage) |
| Pneumatic Supply | Clean, dry compressed air at 0.8 - 1.0 MPa |
| Cooling Water | Chilled water loop for molds; industrial water loop for the hydraulic system |
Material Compatibility & Multi-Layer CoEx Technology
We engineer every BlowPacker automatic extrusion blow molding machine for sale to handle a diverse range of resins and complex layer structures. Our advanced parison control system ensures uniform wall thickness regardless of the material compound used.
Compatible Thermoplastics
Our plastic processing equipment runs standard, engineering, and recycled resins smoothly. We optimize our screw and barrel designs to prevent material degradation and ensure a flawless surface finish.
- HDPE (High-Density Polyethylene): The industry standard for heavy-duty applications. Perfect for high-output HDPE container blow molder operations.
- PP (Polypropylene): Ideal for products requiring high-temperature resistance, clarity, and living hinges.
- LDPE & LLDPE: Selected for flexible, squeezable personal care and food packaging.
- PETG, PVC, & PC: Supported for specialized applications requiring high impact strength or crystal-clear transparency.
Multi-Layer Configurations (1 to 6 Layers)
To reduce raw material costs and add barrier protection, we equip our machines with cutting-edge co-extrusion multi-layer blow molding technology.
| Layer Setup | Common Applications | Primary Benefit |
|---|---|---|
| Mono-Layer (1 Layer) | Standard bottles, simple industrial parts | Cost-effective and straightforward production. |
| 3-Layer (CoEx) | Cosmetics, household chemicals | Allows the use of recycled plastic (PCR) in the middle layer while keeping virgin plastic on the outside. |
| 6-Layer (High-Barrier) | Automotive fuel tanks, agrochemical jerrycans | Incorporates EVOH or Nylon barrier layers to prevent chemical permeation and odor leakage. |
Versatile Applications for Our Automatic Extrusion Blow Molding Machine for Sale
We engineer our fully automatic EBM machines to handle diverse manufacturing demands across the United States. Whether you need high-volume retail containers or rugged industrial parts, our systems deliver consistent wall thickness, high structural integrity, and fast cycle times.
Consumer Packaging
Our plastic processing machinery excels in producing high-gloss, pristine containers for daily consumer goods with minimal scrap.
Beverages & Dairy: High-speed production of lightweight milk jugs and juice bottles.
Personal Care: Sleek, multi-layer bottles for shampoos, lotions, and cosmetics.
Household Cleaners: Durable HDPE containers that resist cracking and chemical degradation.
Industrial & Chemical Packaging
Safety, drop-resistance, and chemical barrier properties are critical for heavy-duty industrial storage. Our machinery ensures high-strength seams for demanding applications.
Jerrycans & Pails: High-performance jerrycan blow molding machine setups for tight-head containers.
Agrochemical Storage: Multi-layer barrier bottles designed to prevent chemical permeation.
Bulk Drums: Robust hollow plastic bins built to withstand rough logistics handling.
Automotive Components
The US automotive sector requires tight tolerances, complex geometries, and lightweight designs. Our industrial hollow plastic manufacturing equipment easily meets strict OEM standards.
Fluid Reservoirs: Precision molding for windshield washer tanks, brake fluid reservoirs, and coolant overflow bottles.
Air Ducts: Complex, lightweight blow-molded air intake ducts that fit tight engine bay configurations.
Large Hollow Parts
For oversized items, our high-clamping-force systems manage heavy parisons without sagging or technical deformation.
Outdoor Goods: Weather-resistant trash cans, rain barrels, and heavy-duty plastic pallets.
Construction Materials: Durable road safety barriers, drums, and large-capacity water storage tanks.
Automatic Extrusion Blow Molding — Downstream Integration
We provide complete turnkey solutions that transform your automatic extrusion blow molding machine for sale from a standalone unit into a fully automated production line. By eliminating manual handling, we help US manufacturers maximize efficiency, reduce labor costs, and maintain high product consistency.
In-Line Deflashing & Trimming
Our system handles the entire post-molding process automatically.
Precision trimming: Removes top, bottom, and handle flash instantly.
Clean cuts: Ensures smooth necks and perfect sealing surfaces on every HDPE container blow molder.
Zero secondary handling: Parts move directly to the next stage without human intervention.
Quality Control Systems
Protect your brand and eliminate waste with integrated inspection technology that checks every single part.
Leak testing: High-speed, in-line pressure testing rejects defective bottles instantly.
Vision inspection: Cameras check neck finish, wall thickness, and overall geometry.
Weight monitoring: Keeps a strict eye on material distribution to guarantee strict compliance with US packaging standards.
Robotic Take-Out & Conveying
We integrate advanced automation to move finished products quickly and safely down the line.
Custom take-out grips: Robots safely remove hot parts from the clamping unit without causing deformation.
Smart conveying: Modular conveyor belts organize, orient, and transport bottles seamlessly.
Palletizer ready: Easily connects to downstream packing and palletizing equipment.
Closed-Loop Scrap Recycling
Maximize your material efficiency and lower your production costs by recycling scrap instantly.
| Feature | How It Works | Benefit for Your Factory |
|---|---|---|
| Direct Regrind | Flash and scrap drop directly into an under-the-machine granulator. | Eliminates manual scrap collection and storage. |
| Proportional Mixing | Regrind is automatically blended back with virgin resin. | Maintains exact material recipes without manual calculations. |
| Dust Separation | The system filters out fine dust before re-introducing the plastic. | Protects the continuous extrusion blow molding system from contamination. |
Key Components & Premium Brand Integration
We know that your production line is only as reliable as its weakest part. That is why our automatic extrusion blow molding machine for sale is built exclusively with world-class components from industry-leading brands. By integrating top-tier global parts into our plastic processing machinery, we ensure maximum uptime, easy maintenance, and long-term durability for your factory floor.
Hydraulic & Pneumatic Systems
High-speed advanced automation requires fluid, precise movements. We equip our machines with rugged hydraulic and pneumatic systems that stand up to continuous, heavy-duty production cycles.
Valves & Pumps: Genuine Rexroth or Yuken components ensure stable clamping unit force and smooth carriage strokes.
Pneumatics: Festo or SMC actuators handle high-speed parison cutting and part ejection without fail.
Electrical & Control Components
Smart manufacturing relies on brains as much as brawn. Our control systems deliver pinpoint accuracy and user-friendly operation for North American operators.
PLCs & HMIs: High-end Siemens or Omron control systems feature intuitive touchscreens and real-time diagnostics.
Parison Control System: Integrated Moog parison controllers manage wall thickness flawlessly to optimize material usage and reduce container weight.
Safety Hardware: Schneider or Banner safety relays and sensors to meet strict workplace safety standards.
Extruder Drives
Consistent melt quality starts with a powerful, stable drive system. Our extruders are engineered to deliver steady plastic output while slashing energy bills.
Motors & Inverters: Premium ABB or Siemens AC variable-frequency drives offer precise speed control and high-energy efficiency.
Gearboxes: Heavy-duty, high-torque gearboxes designed specifically for continuous extrusion blow molding system demands, minimizing heat buildup and mechanical wear.
Buyers cross-shopping legacy pre-owned equipment from brands such as Bekum, Jomar, Sterling, or Apollo on used-market listings should compare clamping force, parison control systems, and opening stroke against these new-build specifications before committing to refurbishment costs.
BlowPacker Global Service & Support
When you invest in a BlowPacker automatic extrusion blow molding machine for sale, you get full lifecycle support from our team of US-based and global experts.
Custom Engineering & Mold Design
Every manufacturing line has unique demands. We collaborate with your team to design and engineer custom molds and extrusion blow moulding machinery setups tailored to your specific product dimensions, shrinkage rates, and material choices.
Factory Acceptance Testing (FAT)
Before any fully automatic EBM machine leaves our floor, it undergoes rigorous Factory Acceptance Testing. We run the equipment under real production conditions using your specified resins to guarantee it hits your cycle time and quality benchmarks before shipping.
Installation & Commissioning
Our field engineers manage the on-site installation, startup, and fine-tuning of your energy-saving blow molder. We also provide hands-on operator training to ensure your team can safely maximize throughput from day one.
After-Sales & Spare Parts Support
Minimizing downtime is our top priority. We maintain a robust inventory of premium components and wear parts for quick dispatch across the US.
- 24/7 Technical Support: Direct access to experienced technicians.
- Rapid Parts Delivery: Fast shipping on critical mechanical and electrical components.
- Remote Diagnostics: Quick troubleshooting via integrated control systems to get you back online fast.
Ordering Information & Lead Times
As a direct automatic extrusion blow molding machine wholesaler, BlowPacker publishes transparent factory price automatic extrusion blow molding machine bands and wholesale price automatic extrusion blow molding machine tiers for multi-unit programs — not broker markups on auction used blow molding machines.
| Pricing Tier | Typical Scope | Notes |
|---|---|---|
| Low price automatic extrusion blow molding machine | BP-EBM25 · mono-layer · standard deflash | Cheap price automatic extrusion blow molding machine entry from ~$19,000 FOB depending on configuration |
| Factory price automatic extrusion blow molding machine | BP-EBM45 · CoEx 3-layer · QC package | Mid-range plastic processing equipment with parison control systems |
| Wholesale price automatic extrusion blow molding machine | BP-EBM90 · turnkey + automation | Volume quotes for 2+ lines · MOQ typically 1 set per model |
Standard configurations ship in 3–4 months; custom turnkey lines with downstream advanced automation require 4–6 months including mold design. For a detailed quote on your automatic extrusion blow molding machine for sale configuration, request a quote with target container volume, resin, and annual output.
Automatic Extrusion Blow Molding Machine for Sale — FAQ
What is the difference between continuous extrusion and accumulator head blow molding?
The main difference lies in how the plastic parison is formed and dropped. We design both systems to match specific product weights and sizes.
| Feature | Continuous Extrusion Blow Molding System | Accumulator Head Blow Molding Machine |
|---|---|---|
| How it Works | Plastic flows constantly; the parison forms continuously. | Plastic collects in a chamber first, then pushes out fast. |
| Best For | High-volume, smaller items (e.g., automatic plastic bottle making machine lines). | Heavy, large hollow plastic manufacturing equipment (e.g., drums, tanks). |
| Material Strength | Standard. | Higher, prevents the hot plastic from stretching or sagging. |
Can BlowPacker machines process recycled plastic (PCR)?
Yes. We engineer our plastic processing machinery to handle post-consumer recycled (PCR) plastics seamlessly. Our multi-layer co-extrusion technology lets you sandwich recycled material between layers of virgin plastic, maintaining container strength while dropping your raw material costs.
What is the lead time for a custom automatic extrusion blow molding machine?
- Standard configurations: 3 to 4 months.
- Custom turnkey solutions: 4 to 6 months (includes custom mold design and downstream automation).
As a direct automatic extrusion blow molding machine wholesaler, we control the entire manufacturing timeline to ensure your equipment arrives on schedule.
How does the automatic deflashing system work?
Our fully automatic EBM machine lineups feature built-in, in-line deflashing. Once the mold opens, integrated mechanical trims automatically punch away excess scrap plastic from the neck, bottom, and handles. The trimmed scrap drops directly into a closed-loop granulator for immediate recycling, keeping your factory floor clean and efficient.
Do you assist with mold design and manufacturing?
Yes. We are a premier Blow Molding Machines manufacturer and supplier, offering complete end-to-end engineering. Our team designs, tests, and manufactures high-precision molds tailored exactly to your product specs—whether you are producing a lightweight HDPE container blow molder bottle or a heavy-duty jerrycan blow molding machine part.
Do you sell used blow molding machines or pre-owned equipment?
BlowPacker supplies new automatic extrusion blow molding machine for sale builds with full warranty, FAT, and commissioning — not brokered pre-owned equipment. Buyers evaluating used blow molding machines on auction or dealer sites should verify clamping force, carriage stroke, and control systems against our new factory price automatic extrusion blow molding machine bands before assuming lower upfront cost equals lower total cost of ownership. For process background on EBM vs stretch lines, see automatic blow molding machine process.
